Build a Fully-Onchain Image Gallery

info

The FlowtoBooth tutorial series teaches you how to build a fun benchmark app and provides inspiration for the greater scope of possibilities building on Flow thanks to gas being so much less expensive.

It is not a production best-practice. While everything in these tutorials works, you'll run into the following problems at production scale:

• RPC Providers will likely rate-limit you for reading this much data at once
• NFT marketplaces may not display the images, likely due to the above
• 256*256 images are huge by blockchain data standards, but too small for modern devices

If you search for resources on how to store images of any significant size onchain, you'll be told it's either prohibitively expensive or even completely impossible. The reason for this is two-fold - first the size limit for data on transactions is about 40kb. Second, saving 40kb takes almost all of the 30 million gas limit on most blockchains.

The former constraint is immutable (though many chains are slowly increasing this limit), which limits the app to images about 256*256 pixels in size. The latter is heavily dependent on which chain you choose.

At current gas prices on most chains, using all 30 million gas in a block costs several dollars - or potentially thousands on ETH mainnet. At current prices on Flow, spending 30 million gas costs less than a penny, usually 1 or 2 tenths of a cent.

Much more computation is available at prices you or your users will be willing to pay for regular interactions. Including, but not limited to:

• Airdropping hundreds of NFTs with one transaction, for pennies
• Generation of large mazes
• Generating large amounts of random numbers (with free native VRF)
• Extensive string manipulation onchain
• Simple game AI logic

In this tutorial, we'll build a smart contract that can store and retrieve images onchain. We'll also build a simple frontend to interact with the contract on Flow and another chain.

Objectives

After completing this guide, you'll be able to:

• Construct a composable onchain image gallery that can be used permissionlessly by onchain apps and other contracts to store and retrieve images
• Build an onchain app that can interact with this contract to save and display images
• Compare the price of spending 30 million gas on Flow with the price on other chains

Prerequisites

Next.js and Modern Frontend Development

This tutorial uses Next.js. You don't need to be an expert, but it's helpful to be comfortable with development using a current React framework. You'll be on your own to select and use a package manager, manage Node versions, and other frontend environment tasks.

Solidity

You don't need to be an expert, but you should be comfortable writing code in Solidity. You can use Hardhat, Foundry, or even Remix.

Build an Image Gallery Contract

Start a new smart contract project in the toolchain of your choice and install the OpenZeppelin contracts.

In your project, stub out a new contract for your image gallery that inherits from the Ownable contract:

_10

// ImageGallery.sol

_10

_10

// SPDX-License-Identifier: MIT

_10

pragma solidity ^0.8.28;

_10

_10

import "@openzeppelin/contracts/access/Ownable.sol";

_10

_10

contract ImageGallery is Ownable {

_10

constructor(address _owner) Ownable(_owner) {}

_10

}

We're passing the original owner of the contract as an argument in the constructor to give greater flexibility for ownership when this contract is deployed.

Set Up Storage for Images

We'll store the images in a simple struct that holds the image as a base64 encoded stringand also contains a string for the description. Doing so allows the image to be directly used in html and makes it easier to test the contract directly with a block explorer, but has the downside of making the images 33% bigger. Another format would be more efficient.

These will be held in array:

_10

struct Image {

_10

string description;

_10

string base64EncodedImage;

_10

}

_10

_10

Image[] public images;

Construct Functions to Add and Delete Images

Next, add a function that accepts a _description and _base64EncodedImage and adds them to the array.

_10

function addImage(

_10

string memory _description,

_10

string memory _base64EncodedImage

_10

) public onlyOwner {

_10

images.push(Image(_description, _base64EncodedImage));

_10

}

Then, add one to delete the image at a given index:

_10

function deleteImage(uint256 index) public onlyOwner {

_10

if (index >= images.length) {

_10

revert ImageIndexOutOfBounds(index, images.length);

_10

}

_10

for (uint256 i = index; i < images.length - 1; i++) {

_10

images[i] = images[i + 1];

_10

}

_10

images.pop();

_10

}

warning

If the array gets big enough that calling deleteImage takes more than 30 million gas, it will brick this function. A safer and more gas-efficient method is to use a mapping with a counter as the index, and handling for the case where an index is empty.

We're doing it this way to provide a way to delete accidentally uploaded images without making things too complex.

Retrieval Functions

Finally, add functions to get one image, get all of the images, and get the number of images in the collection.

_14

function getImages() public view returns (Image[] memory) {

_14

return images;

_14

}

_14

_14

function getImage(uint256 index) public view returns (Image memory) {

_14

if (index >= images.length) {

_14

revert ImageIndexOutOfBounds(index, images.length);

_14

}

_14

return images[index];

_14

}

_14

_14

function getImageCount() public view returns (uint256) {

_14

return images.length;

_14

}

Final Contract

After completing the above, you'll end up with a contract similar to:

_49

// SPDX-License-Identifier: UNLICENSED

_49

pragma solidity ^0.8.28;

_49

_49

import "@openzeppelin/contracts/access/Ownable.sol";

_49

_49

contract ImageGallery is Ownable {

_49

struct Image {

_49

string description;

_49

string base64EncodedImage;

_49

}

_49

_49

Image[] public images;

_49

_49

error ImageIndexOutOfBounds(uint256 index, uint256 length);

_49

_49

constructor(address _owner) Ownable(_owner) {}

_49

_49

function addImage(

_49

string memory _description,

_49

string memory _base64EncodedImage

_49

) public onlyOwner {

_49

images.push(Image(_description, _base64EncodedImage));

_49

}

_49

_49

function deleteImage(uint256 index) public onlyOwner {

_49

if (index >= images.length) {

_49

revert ImageIndexOutOfBounds(index, images.length);

_49

}

_49

for (uint256 i = index; i < images.length - 1; i++) {

_49

images[i] = images[i + 1];

_49

}

_49

images.pop();

_49

}

_49

_49

function getImages() public view returns (Image[] memory) {

_49

return images;

_49

}

_49

_49

function getImage(uint256 index) public view returns (Image memory) {

_49

if (index >= images.length) {

_49

revert ImageIndexOutOfBounds(index, images.length);

_49

}

_49

return images[index];

_49

}

_49

_49

function getImageCount() public view returns (uint256) {

_49

return images.length;

_49

}

_49

}

Create a Factory

The image gallery contract you've just constructed is intended to be a utility for other contracts and apps to use freely. You don't want just one gallery for everyone, you need to give the ability for any app or contract to create and deploy private galleries freely.

Build a factory to deploy image galleries:

_13

pragma solidity ^0.8.28;

_13

_13

import "@openzeppelin/contracts/access/Ownable.sol";

_13

import "./ImageGallery.sol";

_13

_13

contract ImageGalleryFactory {

_13

event ImageGalleryCreated(address indexed owner, address gallery);

_13

_13

function createImageGallery(address _owner) public {

_13

ImageGallery gallery = new ImageGallery(_owner);

_13

emit ImageGalleryCreated(_owner, address(gallery));

_13

}

_13

}

Tracking Factories

Some app designs may need multiple galleries for each user. For example, you might want to be able to give users the ability to collect images in separate galleries for separate topics, dates, or events, similar to how many photo apps work on smartphones.

To facilitate this feature, update your contract to keep track of which galleries have been created by which users. You'll end up with:

_23

// SPDX-License-Identifier: UNLICENSED

_23

pragma solidity ^0.8.28;

_23

_23

import "@openzeppelin/contracts/access/Ownable.sol";

_23

import "./ImageGallery.sol";

_23

_23

contract ImageGalleryFactory {

_23

event ImageGalleryCreated(address indexed owner, address gallery);

_23

_23

mapping(address => address[]) userToGalleries;

_23

_23

function createImageGallery(address _owner) public {

_23

ImageGallery gallery = new ImageGallery(_owner);

_23

emit ImageGalleryCreated(_owner, address(gallery));

_23

userToGalleries[_owner].push(address(gallery));

_23

}

_23

_23

function getGalleries(

_23

address _owner

_23

) public view returns (address[] memory) {

_23

return userToGalleries[_owner];

_23

}

_23

}

Testing the Factory

Write appropriate unit tests, then deploy and verify the factory on Flow Testnet.

If you need help, check out:

• Deploy and Verify with Hardhat
• Deploy and Verify with Foundry
• Deploy and Verify with Remix

Navigate to evm-testnet.flowscan.io, search for your contract, and navigate to the contracts tab, then Read/Write contract. You'll see something similar to:

Connect your wallet. Use the Flow Wallet if you want automatically sponsored gas on both mainnet and testnet, or use the Flow Faucet to grab some testnet funds if you prefer to use another wallet.

Expand the createImageGallery function, click the self button, and then Write the function.

Approve the transaction and wait for it to complete. Then, call getGalleries for your address to find the address of the gallery you've created.

Testing the Image Gallery

Search for the address of your image gallery contract. It won't be verified, but if you're using our exact contract, you will see a message from Flowscan that a verified contract with the same bytecode was found in the Blockscout DB. Click the provided link to complete the verification process.

info

The easiest way to get an ABI for the image gallery is to deploy one. You can do that now if you like.

If you're following along, but used your own contract, simply deploy and verify one copy of the contract directly, refresh the page, then complete the above.

You could test addImage with a random string, but it's better to use a base64-encoded image. Search for and navigate to one of the many online tools that will base64 encode images.

danger

Most sites of this nature are free tools created by helpful programmers and are funded with ads, donations, or the generosity of the creator. But you never know who made them or what they're caching.

Never upload or convert sensitive data on a free site.

Use the tool to convert an image that is ~30kb or smaller. Copy the string and paste it into the field in addImage. You can also add a description, but the bytes used will count towards the ~40kb limit.

Click Write and approve the transaction. Take note of the cost! You've saved an image onchain forever for just a little bit of gas!

Once the transaction goes through, call getImage with 0 as the index to retrieve your description and base64-encoded image.

Paste your image string as the src for an img tag in an html snippet to confirm it worked.

_10

<div>

_10

<img

_10


_10

/>

_10

</div>

Building the Frontend

Now that your contracts are sorted and working, it's time to build an app to interact with it. We'll use Next.js for this, but the components we provide will be adaptable to other React frameworks.

Run:

_10

npx create-next-app

We're using the default options.

Next, install rainbowkit, wagmi, and their related dependencies:

_10

npm install @rainbow-me/rainbowkit wagmi viem@2.x @tanstack/react-query

Provider Setup

Add a file called providers inside the app folder. In it, add your config and providers for wagmi and rainbowkit. You'll need to add the Flow Wallet as a custom wallet. It's not included by default because it has special features that aren't compatible with other blockchains.

_115

'use client';

_115

_115

import { connectorsForWallets } from '@rainbow-me/rainbowkit';

_115

import { Wallet, getWalletConnectConnector } from '@rainbow-me/rainbowkit';

_115

import { QueryClient, QueryClientProvider } from '@tanstack/react-query';

_115

import { createConfig, WagmiProvider } from 'wagmi';

_115

import { RainbowKitProvider } from '@rainbow-me/rainbowkit';

_115

import { flowTestnet } from 'viem/chains';

_115

import { http } from 'wagmi';

_115

_115

const projectId = '51407fcf066d74968d9a1a4c6da0d994'; // Replace with your actual project ID

_115

_115

export interface MyWalletOptions {

_115

projectId: string;

_115

}

_115

_115

const flowWallet = ({ projectId }: MyWalletOptions): Wallet => ({

_115

id: 'flow-wallet',

_115

name: 'Flow Wallet',

_115

rdns: 'com.flowfoundation.wallet',

_115

iconUrl: 'https://lilico.app/logo_mobile.png',

_115

iconBackground: '#41CC5D',

_115

downloadUrls: {

_115

android:

_115

'https://play.google.com/store/apps/details?id=com.flowfoundation.wallet',

_115

ios: 'https://apps.apple.com/ca/app/flow-wallet-nfts-and-crypto/id6478996750',

_115

chrome:

_115

'https://chromewebstore.google.com/detail/flow-wallet/hpclkefagolihohboafpheddmmgdffjm',

_115

qrCode: 'https://link.lilico.app',

_115

},

_115

mobile: {

_115

getUri: (uri: string) =>

_115

`https://fcw-link.lilico.app/wc?uri=${encodeURIComponent(uri)}`,

_115

},

_115

qrCode: {

_115

getUri: (uri: string) => uri,

_115

instructions: {

_115

learnMoreUrl: 'https://wallet.flow.com',

_115

steps: [

_115

{

_115

description:

_115

'We recommend putting Flow Wallet on your home screen for faster access to your wallet.',

_115

step: 'install',

_115

title: 'Open the Flow Wallet app',

_115

},

_115

{

_115

description:

_115

'You can find the scan button on home page, a connection prompt will appear for you to connect your wallet.',

_115

step: 'scan',

_115

title: 'Tap the scan button',

_115

},

_115

],

_115

},

_115

},

_115

extension: {

_115

instructions: {

_115

learnMoreUrl: 'https://wallet.flow.com',

_115

steps: [

_115

{

_115

description:

_115

'We recommend pinning Flow Wallet to your taskbar for quicker access to your wallet.',

_115

step: 'install',

_115

title: 'Install the Flow Wallet extension',

_115

},

_115

{

_115

description:

_115

'Be sure to back up your wallet using a secure method. Never share your secret phrase with anyone.',

_115

step: 'create',

_115

title: 'Create or Import a Wallet',

_115

},

_115

{

_115

description:

_115

'Once you set up your wallet, click below to refresh the browser and load up the extension.',

_115

step: 'refresh',

_115

title: 'Refresh your browser',

_115

},

_115

],

_115

},

_115

},

_115

createConnector: getWalletConnectConnector({ projectId }),

_115

});

_115

_115

const connectors = connectorsForWallets(

_115

[

_115

{

_115

groupName: 'Recommended',

_115

wallets: [flowWallet],

_115

},

_115

],

_115

{

_115

appName: 'Onchain Image Gallery',

_115

projectId: projectId,

_115

},

_115

);

_115

_115

const wagmiConfig = createConfig({

_115

connectors,

_115

chains: [flowTestnet],

_115

ssr: true,

_115

transports: {

_115

[flowTestnet.id]: http(),

_115

},

_115

});

_115

_115

export default function Providers({ children }: { children: React.ReactNode }) {

_115

const queryClient = new QueryClient();

_115

_115

return (

_115

<WagmiProvider config={wagmiConfig}>

_115

<QueryClientProvider client={queryClient}>

_115

<RainbowKitProvider>{children}</RainbowKitProvider>

_115

</QueryClientProvider>

_115

</WagmiProvider>

_115

);

_115

}

Add the Connect Button

Open page.tsx and clear out the default content. Replace it with a message about what your app does and add the rainbowkit Connect button. Don't forget to import rainbowkit's css file and the ConnectButton component:

_25

import '@rainbow-me/rainbowkit/styles.css';

_25

_25

import { ConnectButton } from '@rainbow-me/rainbowkit';

_25

_25

export default function Home() {

_25

return (

_25

<div className="grid grid-rows-[20px_1fr_20px] items-center justify-items-center min-h-screen p-8 pb-20 gap-16 sm:p-20 font-[family-name:var(--font-geist-sans)]">

_25

<main className="flex flex-col gap-8 row-start-2 items-center sm:items-start">

_25

<h1 className="text-4xl font-bold">Image Gallery</h1>

_25

<p className="text-lg text-center sm:text-left">

_25

A decentralized image gallery built on Flow blockchain. All images

_25

saved directly onchain.

_25

</p>

_25

<p className="text-lg text-center sm:text-left">

_25

A fun benchmark, not best practice for production!

_25

</p>

_25

<p className="text-lg text-center sm:text-left">

_25

Free with gas sponsored by Flow with the Flow wallet. Sub-cent to save

_25

an image with other wallets.

_25

</p>

_25

<ConnectButton />

_25

</main>

_25

</div>

_25

);

_25

}

Test the app and make sure you can connect your wallet.

Import Your Contracts

Next, you'll need to get your contract ABI and address into your frontend. If you're using Hardhat, you can use the artifacts produced by the Ignition deployment process. If you're using Foundry or Remix, you can adapt this process to the format of artifacts produced by those toolchains.

tip

If you didn't deploy the Image Gallery contract, do so now to generate an artifact containing the ABI.

Add a folder in app called contracts. Copy the following files from your smart contract project, located in the ignition and ignition/deployments/chain-545 folders:

• deployed_addresses.json
• ImageGallery#ImageGallery.json
• ImageGalleryFactory#ImageGalleryFactory.json

Additionally, add a file called contracts.ts. In it, create a hook to provide the ABI and addresses of your contracts conveniently:

_22

import { useMemo } from 'react';

_22

import { Abi } from 'viem';

_22

_22

import imageGalleryFactory from './ImageGalleryFactory#ImageGalleryFactory.json';

_22

import imageGallery from './ImageGallery#ImageGallery.json';

_22

import addresses from './deployed_addresses.json';

_22

_22

export default function useContracts() {

_22

return useMemo(() => {

_22

return {

_22

imageGalleryFactory: {

_22

address: addresses[

_22

'ImageGalleryFactory#ImageGalleryFactory'

_22

] as `0x${string}`,

_22

abi: imageGalleryFactory.abi as Abi,

_22

},

_22

imageGallery: {

_22

abi: imageGallery.abi as Abi,

_22

},

_22

};

_22

}, []);

_22

}

info

Note that we're not including an address for the imageGallery itself. We'll need to set this dynamically as users might have more than one gallery.

Add Content

You can use a few strategies to organize the components that interact with the blockchain. One is to create a centralized component that stores all of the state related to smart contracts and uses a single instance of useWriteContract. Doing so makes it easier to convey the transaction lifecycle to your users, at the cost of re-fetching all the data from your RPC provider after every transaction. This becomes sub-optimal if your app interacts with many contracts, or even different read functions within the same contract.

Add a folder in app called components, and create a file called Content.tsx. In it, add the following:

• Imports for React, wagmi, your contracts, and Tanstack
• State variables for:
  • When a reload is needed
  • When you are waiting on a transaction response
  • The list of gallery addresses for the connected wallet
• Hooks for:
  • useAccount()
  • useQueryClient()
  • useContracts()
  • useWriteContract()
  • useWaitForTransactionReceipt()
• useEffects to:
  • Listen for a receipt and set reload to true and awaitingResponse false
  • Listen for needing a reload and invalidating the query for galleryAddresses
  • Error handling
  • Receipt of gallery addresses
• A useReadContract to fetch the list of gallery addresses for this user
• Frontend code to display the button to create a gallery if the user is signed in

You'll end up with something similar to:

_103

'use client';

_103

_103

import { useEffect, useState } from 'react';

_103

import {

_103

useAccount,

_103

useReadContract,

_103

useWaitForTransactionReceipt,

_103

useWriteContract,

_103

} from 'wagmi';

_103

import useContracts from '../contracts/contracts';

_103

import { useQueryClient } from '@tanstack/react-query';

_103

_103

export default function Content() {

_103

const [reload, setReload] = useState(false);

_103

const [awaitingResponse, setAwaitingResponse] = useState(false);

_103

const [galleryAddresses, setGalleryAddresses] = useState<string[]>([]);

_103

_103

const account = useAccount();

_103

const queryClient = useQueryClient();

_103

const { imageGalleryFactory } = useContracts();

_103

_103

const { data, writeContract, error: writeError } = useWriteContract();

_103

_103

const { data: receipt, error: receiptError } = useWaitForTransactionReceipt({

_103

hash: data,

_103

});

_103

_103

useEffect(() => {

_103

if (receipt) {

_103

setReload(true);

_103

setAwaitingResponse(false);

_103

}

_103

}, [receipt]);

_103

_103

useEffect(() => {

_103

if (reload) {

_103

setReload(false);

_103

queryClient.invalidateQueries({ queryKey: galleryAddressesQueryKey });

_103

}

_103

}, [reload]);

_103

_103

useEffect(() => {

_103

if (writeError) {

_103

console.error(writeError);

_103

setAwaitingResponse(false);

_103

}

_103

}, [writeError]);

_103

_103

useEffect(() => {

_103

if (receiptError) {

_103

console.error(receiptError);

_103

setAwaitingResponse(false);

_103

}

_103

}, [receiptError]);

_103

_103

const { data: galleryAddressesData, queryKey: galleryAddressesQueryKey } =

_103

useReadContract({

_103

abi: imageGalleryFactory.abi,

_103

address: imageGalleryFactory.address,

_103

functionName: 'getGalleries',

_103

args: [account.address],

_103

});

_103

_103

useEffect(() => {

_103

if (galleryAddressesData) {

_103

const newAddresses = galleryAddressesData as string[];

_103

newAddresses.reverse();

_103

setGalleryAddresses(newAddresses);

_103

}

_103

}, [galleryAddressesData]);

_103

_103

function handleCreateGallery() {

_103

setAwaitingResponse(true);

_103

writeContract({

_103

abi: imageGalleryFactory.abi,

_103

address: imageGalleryFactory.address,

_103

functionName: 'createImageGallery',

_103

args: [account.address],

_103

});

_103

}

_103

_103

return (

_103

<div className="card gap-1">

_103

{account.isConnected && (

_103

<div>

_103

<div className="mb-4">

_103

<button

_103

onClick={handleCreateGallery}

_103

disabled={awaitingResponse}

_103

className={`px-4 py-2 rounded-lg text-white ${

_103

!awaitingResponse

_103

? 'bg-blue-500 hover:bg-blue-600'

_103

: 'bg-gray-300 cursor-not-allowed'

_103

}`}

_103

>

_103

{awaitingResponse ? 'Processing...' : 'Create Gallery'}

_103

</button>

_103

</div>

_103

</div>

_103

)}

_103

</div>

_103

);

_103

}

Don't forget to add your <Content /> component to page.tsx, below the <ConnectButton /> component.

Test the app and make sure you can complete the transaction to create a gallery.

Gallery List

Next, you'll need to display the list of a user's galleries and enable them to select which one they want to interact with. A dropdown list will serve this function well. Add a component called AddressList.tsx, and in it add:

_42

import React, { useEffect, useState } from 'react';

_42

_42

type AddressDropdownProps = {

_42

addresses: string[]; // Array of EVM addresses

_42

handleSetActiveAddress: Function;

_42

};

_42

_42

const AddressDropdown: React.FC<AddressDropdownProps> = ({

_42

addresses,

_42

handleSetActiveAddress,

_42

}) => {

_42

const [selectedAddress, setSelectedAddress] = useState('');

_42

_42

useEffect(() => {

_42

if (selectedAddress) {

_42

console.log(selectedAddress);

_42

handleSetActiveAddress(selectedAddress);

_42

}

_42

}, [selectedAddress]);

_42

_42

return (

_42

<div className="container mx-auto px-4">

_42

<h1 className="text-2xl font-bold text-center mb-6">Select a Gallery</h1>

_42

<div className="flex flex-col items-center space-y-4">

_42

<select

_42

value={selectedAddress}

_42

onChange={(e) => setSelectedAddress(e.target.value)}

_42

className="w-full max-w-md border border-gray-300 rounded-lg p-2 bg-white shadow-md focus:outline-none focus:ring-2 focus:ring-blue-500"

_42

>

_42

<option value="">Select an address</option>

_42

{addresses.map((address, index) => (

_42

<option key={index} value={address}>

_42

{address}

_42

</option>

_42

))}

_42

</select>

_42

</div>

_42

</div>

_42

);

_42

};

_42

_42

export default AddressDropdown;

This component doesn't interact directly with the blockchain. It accepts the array of addresses and a function to handle setting the activeAddress.

To use it in Content.tsx, you'll need to add a new state variable for the activeAddress:

_10

const [activeAddress, setActiveAddress] = useState<string | null>(null);

You'll also need a handler for when the activeAddress is set. You can't just use the setActiveAddress() function because you need to tell the app to reload if the user changes which gallery is active, so that the images in that gallery are loaded.

_10

function handleSetActiveAddress(address: string) {

_10

setReload(true);

_10

setActiveAddress(address);

_10

}

Finally, add the new component under the <button>:

_10

<AddressList

_10

addresses={galleryAddresses}

_10

handleSetActiveAddress={handleSetActiveAddress}

_10

/>

Test again, and confirm that the address of the gallery you created is in the dropdown and is selectable. The provided code contains a console log as well, to make it easier to copy the address in case you need to check it on Flowscan.

Display the Images

Next, you need to pull the images for the selected gallery from the contract.

warning

Make sure you're using the same gallery you added an image too earlier. Otherwise, there won't be an image to pull and display!

Create a component called ImageGallery. All this needs to do is accept a list of images and descriptions and display them. You can style this nicely if you'd like, or use the basic implementation here:

_55

export type ImageGalleryImage = {

_55

description: string;

_55

base64EncodedImage: string;

_55

};

_55

_55

type ImageGalleryProps = {

_55

images: ImageGalleryImage[]; // Array of image objects

_55

};

_55

_55

const ImageGallery: React.FC<ImageGalleryProps> = ({ images }) => {

_55

if (images.length === 0) {

_55

return (

_55

<div className="container mx-auto px-4">

_55

<p className="text-center text-xl font-bold">No images to display</p>

_55

</div>

_55

);

_55

}

_55

_55

return (

_55

<div className="container mx-auto px-4">

_55

<div className="grid grid-cols-2 md:grid-cols-3 lg:grid-cols-4 gap-4">

_55

{images.map((image, index) => {

_55

const isValidBase64Image =

_55

typeof image.base64EncodedImage === 'string' &&

_55


_55

image.base64EncodedImage.includes('base64,');

_55

_55

return (

_55

<div

_55

key={index}

_55

className="border border-gray-200 rounded-lg overflow-hidden shadow-md"

_55

>

_55

{isValidBase64Image ? (

_55

<img

_55

src={image.base64EncodedImage}

_55

alt={image.description || `Image ${index + 1}`}

_55

className="w-full h-auto object-cover"

_55

/>

_55

) : (

_55

<div className="p-4 text-center text-red-500">

_55

Invalid image data

_55

</div>

_55

)}

_55

<div className="p-2 bg-gray-100 text-center text-sm text-gray-700">

_55

{image.description || 'No description available'}

_55

</div>

_55

</div>

_55

);

_55

})}

_55

</div>

_55

</div>

_55

);

_55

};

_55

_55

export default ImageGallery;

Implementing the gallery display will take more additions to Content.tsx. You'll need to:

• Add a state variable for the list of images
• Implement a second useContractRead hook to pull the images from the currently selected gallery address
• Hook the gallery into the refresh logic

First, add the state variable to store the gallery array:

_10

const [images, setImages] = useState<ImageGalleryImage[]>([]);

Next, add a useReadContract to read from the gallery. Use the activeAddress for the address property. Don't forget to destructure imageGallery from useContracts

_10

const [images, setImages] = useState<ImageGalleryImage[]>([]);

_10

const { data: galleryData, queryKey: galleryQueryKey } = useReadContract({

_10

abi: imageGallery.abi,

_10

address: activeAddress as `0x${string}`,

_10

functionName: 'getImages',

_10

});

Hook the new query key into the refresh system:

_10

useEffect(() => {

_10

if (reload) {

_10

setReload(false);

_10

queryClient.invalidateQueries({ queryKey: galleryAddressesQueryKey });

_10

// Added to existing `useEffect`

_10

queryClient.invalidateQueries({ queryKey: galleryQueryKey });

_10

}

_10

}, [reload]);

Then, add a useEffect to update the images in state when galleryData is received. Users expect the newest images to be shown first, so reverse the array before setting it to state.

_10

useEffect(() => {

_10

if (galleryData) {

_10

const newImages = galleryData as ImageGalleryImage[];

_10

// reverse the array so the latest images are shown first

_10

newImages.reverse();

_10

setImages(newImages);

_10

}

_10

}, [galleryData]);

Finally, implement the gallery itself in the return:

_28

return (

_28

<div className="card gap-1">

_28

{account.isConnected && (

_28

<div>

_28

<div className="mb-4">

_28

<button

_28

onClick={handleCreateGallery}

_28

disabled={awaitingResponse}

_28

className={`px-4 py-2 rounded-lg text-white ${

_28

!awaitingResponse

_28

? 'bg-blue-500 hover:bg-blue-600'

_28

: 'bg-gray-300 cursor-not-allowed'

_28

}`}

_28

>

_28

{awaitingResponse ? 'Processing...' : 'Create Gallery'}

_28

</button>

_28

<AddressList

_28

addresses={galleryAddresses}

_28

handleSetActiveAddress={handleSetActiveAddress}

_28

/>

_28

</div>

_28

<div className="mb-4">

_28

<ImageGallery images={images} />

_28

</div>

_28

</div>

_28

)}

_28

</div>

_28

);

Run the app, log in with your wallet that has the gallery you created for testing and select the gallery.

You're now displaying an image that is stored onchain forever!

Image Uploader

The last thing to do for this initial implementation is to add functionality so that users can upload their own images through the app and save them onchain without needing to do the base64 conversion on their own.

For now, we'll just generate an error if the file is too big, but later on we can do that for the user as well.

Add the ImageUploader component. This needs to handle uploading the image and displaying any errors. We'll keep the state for the image itself in Content so that it's accessible to other components:

_64

import React, { useState } from 'react';

_64

_64

type ImageUploaderProps = {

_64

setUploadedBase64Image: (base64: string) => void; // Function to set the uploaded base64 image

_64

};

_64

_64

const ImageUploader: React.FC<ImageUploaderProps> = ({

_64

setUploadedBase64Image,

_64

}) => {

_64

const [error, setError] = useState<string | null>(null);

_64

_64

const handleImageUpload = (event: React.ChangeEvent<HTMLInputElement>) => {

_64

const file = event.target.files?.[0];

_64

_64

if (!file) {

_64

setError('No file selected');

_64

return;

_64

}

_64

_64

if (!file.type.startsWith('image/')) {

_64

setError('Only image files are allowed');

_64

return;

_64

}

_64

_64

if (file.size > 30 * 1024) {

_64

setError('Image size must be 30KB or smaller');

_64

return;

_64

}

_64

_64

const reader = new FileReader();

_64

reader.onload = () => {

_64

const base64 = reader.result as string;

_64

setUploadedBase64Image(base64);

_64

setError(null);

_64

};

_64

reader.onerror = () => {

_64

setError('Failed to read file');

_64

};

_64

reader.readAsDataURL(file);

_64

};

_64

_64

return (

_64

<div className="container mx-auto px-4">

_64

<div className="flex flex-col items-center space-y-4">

_64

<label

_64

htmlFor="image-upload"

_64

className="cursor-pointer bg-blue-500 text-white px-4 py-2 rounded-lg shadow-md hover:bg-blue-600"

_64

>

_64

Upload Image

_64

</label>

_64

<input

_64

id="image-upload"

_64

type="file"

_64

accept="image/*"

_64

onChange={handleImageUpload}

_64

className="hidden"

_64

/>

_64

{error && <p className="text-red-500 text-sm">{error}</p>}

_64

</div>

_64

</div>

_64

);

_64

};

_64

_64

export default ImageUploader;

As before, we'll need to make some updates to Content.tsx to complete the implementation.

First, add a state variable for the image:

_10

const [uploadedBase64Image, setUploadedBase64Image] = useState<string>('');

Then add the ImageUploader to the return:

_10

<ImageUploader setUploadedBase64Image={setUploadedBase64Image} />

Later on, you'll probably want to make a component for displaying the uploaded image, but for now just add it below the uploader button component:

_11

{

_11

uploadedBase64Image && (

_11

<div className="mt-6 text-center">

_11

<img

_11

src={uploadedBase64Image}

_11

alt="Uploaded"

_11

className="max-w-xs mx-auto rounded-lg shadow-md"

_11

/>

_11

</div>

_11

);

_11

}

Finally, you need to add a button and a handler to call the smart contract function to save the image onchain.

_10

function handleSaveOnchain() {

_10

// console.log(uploadedBase64Image);

_10

setAwaitingResponse(true);

_10

writeContract({

_10

abi: imageGallery.abi,

_10

address: activeAddress as `0x${string}`,

_10

functionName: 'addImage',

_10

args: ['', uploadedBase64Image],

_10

});

_10

}

Add the button inside the check for an uploadedBase64Image so that it only displays when there is an image to upload:

_22

{

_22

uploadedBase64Image && (

_22

<div className="mt-6 text-center">

_22

<img

_22

src={uploadedBase64Image}

_22

alt="Uploaded"

_22

className="max-w-xs mx-auto rounded-lg shadow-md"

_22

/>

_22

<button

_22

onClick={handleSaveOnchain}

_22

disabled={awaitingResponse}

_22

className={`px-4 py-2 rounded-lg text-white ${

_22

!awaitingResponse

_22

? 'bg-blue-500 hover:bg-blue-600'

_22

: 'bg-gray-300 cursor-not-allowed'

_22

}`}

_22

>

_22

{awaitingResponse ? 'Loading...' : 'Save Onchain'}

_22

</button>

_22

</div>

_22

);

_22

}

Test the app to save your new image, and make sure the error displays if you try to upload an image that is too large.

Conclusion

In this tutorial, you built a fully functional onchain image gallery using Flow EVM. You created smart contracts that can store images directly on the blockchain and a modern React frontend that allows users to interact with these contracts. The implementation demonstrates how Flow's efficient gas pricing makes operations that would be prohibitively expensive on other chains not just possible, but practical.

Now that you have completed the tutorial, you should be able to:

• Construct a composable onchain image gallery that can be used permissionlessly by onchain apps and other contracts to store and retrieve images
• Build an onchain app that can interact with this contract to save and display images
• Compare the price of spending 30 million gas on Flow with the price on other chains

Now that you've completed this tutorial, you're ready to explore more complex onchain storage patterns and build applications that take advantage of Flow's unique capabilities for storing and processing larger amounts of data than traditionally possible on other chains.
